Original Warbird Technical Drawings & Manuals

intro cockpit1 Original Warbird Technical Drawings & Manuals

We have nearly 28,000 original technical drawings and manuals for the Spitfire, Hurricane, Lancaster, Mosquito, Focke Wulf 190 and B-24 Liberator.

These original warbird blueprints and plans are now readily available to help you produce the most accurate restoration or modeling project.

Copyzone Ltd, a UK company, have worked with the Lincolnshire’s Lancaster Association to scan, index and archive these records as part of their efforts to preserve the aviation history of the period.

We have also processed around 100 Warbird Manuals (English and German). We later added around 25,000 B-24M Liberator and 120 FW190 drawings.

intro pic11 Original Warbird Technical Drawings & Manuals

Many of these drawings and Manuals are available to buy online. Just visit the page for the aircraft type to see what is available for immediate download – with the remainder available via email.

Take a look at some samples from our catalogue to confirm the authenticity of these original drawings:

- B24 Drawing Sample (350k)

- FW190 Drawing sample (175k)

- Manual sample (130k)

pdf downloadx200 e1364299275998 Original Warbird Technical Drawings & Manuals

Warbirds Manuals

If you can’t find what you want here online then to search for a particular item, download our catalogue in .pdf format from the respective page, locate the drawings your require then email us to order.

pdf downloadx200 e1364299275998 Original Warbird Technical Drawings & Manuals

Warbirds Engine Manuals

Hawker Hurricane mid section Original Warbird Technical Drawings & Manuals

Our aim is to continually expand our drawings database. If you have any drawings of any Warbirds and would like to discuss the sale or exchange of them we would love to hear from you. We aim to compile an authoritative collection of drawings to serve Warbird Restorers worldwide. We welcome feedback from all our visitors – please visit the Contact page.
